Orange5 Base Set Orange5 is a professional programming device for memory and microcontrollers. Unique feature of the current series programmers is built-in macrolanguage for writing down protocols, which gives fast and easy capability to add new types of microschemes, precisely meeting manufacturers’ requirements to read/write algorithms. Orange5 Technical Information USB power supply (USB2.0/3.0). Universal easy to plug panel ZIF16 for EEPROM Control of contacts in the sockets Two expansions sockets compatible with Orange4 and Omega MTRK Protection against overcurrent Overload voltage protection Two types of power supply: Standart (USB) and enhanced (USB external power supply) Three 3 adjustable voltage and current control: Voltage of power supply ( 2.0…5.0V ), programming voltage (2.0…21.0V), additional static 10V for microcontrollers. High-speed bidirectional pin drivers with adjustable voltage (2.0…5.0V) Wave cycle generator with frequency ( up to 24 Mhz) and out voltage(2.0…5.0V) adjustment. Capability of functional emulation of class CDC USB devices. Built-in 32-bit virtual machine Supported interface: I2C, SPI, MicroWire, JTAG, UART, BDM, ISO7816, K-LINE (via adapter), CAN (via adapter). Supported Operation Systems : Windows XP/7 32bit , Windows 7/8/8.1/10 64bit Orange-5 Quick Links Additional Adapters for Orange5 Additional Software for Orange5 Chiplist Adapters’ Schematics CnCterm O5Tool Logotypes This Pack comes with only; Main Unit, 05BP2 (MTRK adapter), HC11A/Exx, TMS, K/CAN as you see on picture! Product Code: ORA-01
